September 02, 2016


This week I worked on the PR of factoring square free polynomials. Adding many changes for size in base. Like changing this:

auto l = std::ceil(std::log(2 * B + 1) / std::log(mp_get_ui(fsqf.first)));


if (mp_fits_slong_p(B)) {
    temp = 2 * B + 1;
    l = std::ceil(std::log(mp_get_d(temp))
                  / std::log(mp_get_ui(fsqf.first)));
} else {
    auto b_d = mp_get_d(mp_abs(b));
    l = std::ceil(
        (1 + std::log2(n + 1) / 2.0 + n + log2_d_A + std::log2(b_d))
        / (std::log2(mp_get_ui(fsqf.first))));

This prevented over-flow. And a lot of implementation changes were incorporated in gf_gcdex also.

I also wrote documentation on Fields module here.

August 21, 2016

Hi, I'm Gaurav Dhingra (@gxyd) and this post is a report of my work for SymPy under Google Summer of Code 2016.

This is also intended to be a description of my work for submission to GSoC's Final Evaluation.

Work Product Submission

PR for GSoC 2016 product submission: Gaurav Dhingra.

GSoC proposal

Pull Requests

Bugs reported


Brief Information

Project: Group Theory


My Website:

e-mail: axyd0000[at], igauravdhingra[at]

I am a pre-final year undergraduate student of Applied Mathematics at IIT Roorkee.

Before GSoC

I heard about the GSoC program and about SymPy org. since of one of my college mate, Prasoon Shukla (he also participated in GSoC with SymPy). I was quite amazed by how mathematics and computer science could intersect and help in solving math problems.

I have been contributing to SymPy from May last year. In the beginning I tended often to work on issues that were more often related to my then on-going courses in my college. In December I completed a basic course on Group Theory, so I thought of choosing to work on Group Theory and I saw quite a few things in CGT were missing from SymPy and those functionalities were already there in GAP and Magma. So I asked them from Kalevi, regarding things that could be taken up for a gsoc project. So finally with some discussions with him and Aaron, I was sure by December end that I was going to work on implementing Finitely Presented Group in SymPy. I looked upto the last GSoC project on CGT by Alexandar Makelov, for reference material that could be used for the implementation and it turned out that the book by Derek Holt, Handbook of Computational Group Theory (will mention as shortly the Handbook).

Though I already started working on PR #10350 for implementation of free groups in beginning January though I started working on the proposal from February beginning.

So what I should do? Since I was quite sure of the project. Well at that moment I thought, since I am a mathematics major, choosing this project would also help me. So I reached out to Kalevi, said to him what I was thinking to do, what could be good for the project. So we worked upon making a good gsoc proposal.

Here is my GSoC proposal. Now that the summer is over and I've tackled a lot more with computational group theory, it seems that the main points in my GSoC proposal were:

  • Implementation of different algebraic structures monoid, free monoid, free group, semi group, free semi group, magma, etc.
  • Rewriting System for reducing the elements of finitely presented groups.
  • The Todd-Coxeter algorithm for coset enumeration, used to find the index of a subgroup of a finitely presented group.
  • Reidemeister Schreier algorithm.
  • Implementation of main Group class.

Well, I submitted my proposal and needed to wait until April 22 to the result, and then...

I was selected _/\_

I got lucky to have Kalevi Suominen like mentor too. Aaron Meurer, the project leader of SymPy was to be co-mentor, and I felt honored to be alloted my preferred mentors.

During GSoC

A more detailed account of my progress can be found on my blog here

  • We started working on 7th May, we first started with working on completing the Free Group PR#10350 and we discussed things on our channel sympy/GroupTheory. We had some discussion on whether Basic should be a super-class of FreeGroup or not. In the end we decied not to derive FreeGroup from Basic. Its basic methods had already been written, most of them inspired from GAP software.
  • For the first point in my proposal (i.e implementation of algebraic structures), we didn't started with them (infact we never worked on them). We then moved onto the Coset Enumeration which covered 5 weeks of work in my timeline, but we didn't spend that much time, atleast on the first go at that moment, that did took alomost 3 weeks including the implementation of two strategies of enumeration Felsch and HLT. It was the very heart of our GSoC project. There were quite a few bugs that were there in algorithm, especially the bug #11449, to which the Kalevi found the solution.
  • For the second point we never reached it, there wasn't sufficient time for that. Then we decided to rather implement the Low Index Subgroups algortithm. It was quite fun to implement the algorithm, since it gave some good insight into CGT. More on this on blog for week 5.
  • From here I had passed my mid-term evaluations. Then we started with work on Reidemeister Schreier algorithm. The algorithm was mainly implemeted using the Havas paper, though the current implementation in SymPy doesn't produce the best simplifed presentation. No good pseudocode is available for the algorithm, the major difficulty being the sequence of applying the operation. More on this on blog for week 6.
  • After we thought that the result returned by Reidemeister Schreier algorithm we moved onto modified todd coxeter algorithm. The main difficulty in it was defining the $\tau$ which can be read on the our channel for comments by Kalevi, I belive it can help in solving that problem.
  • As to the fifth point (i.e making Group class), we never worked upon it. Also the topic of Presenation of Finite Groups , could not get much attention, since of my busy college schedule.

Commits/Code written during GSoC

Since I have commited quite a few commits un-related to my project. So I decided to cherry-pick the commits made for my GSoC project. So the combined commits makes the things quite clear. commits in GSoC 2016 product submission: Gaurav Dhingra.

Most annoying issue

issue #11449

After GSoC

There is still much to be done regarding the finitely presented groups. As during the program my efforts were directed mainly towards getting the fundamental algorithms for finitely presented groups in, the overall structure of the module hasn't received much attention.

The algorithms are in, but the methods in sympy/combinatorics/ are not that much user-friendly. The code organization is not terrible, I think. Some suggestions (both for me and anyone else interested) for future work are:

  • Cosets in permutation groups: [verbatim-copy of Kalevi's mail - "next thing to do"] Finding cosets in permutation groups is more challenging to implement since there seems to be no ready-made pseudocode. However, there is a description of the procedure with an example in section 4.6.7. It can be based on the existing implementation of the Screier-Sims algorithm.
  • Finitely generated abelian groups: [verbatim-copy of Kalevi's mail - "next thing to do"] There is useful pseudocode in chapter 9 of the book by Holt that should make it fairly easy to implement the basic methods of abelian groups. We should probably try to base the implementation on the code in polys.agca as abelian groups are the same as Z-modules. It is all essentially about linear algebra over the integers.
  • Complete modified Todd Coxeter algorithm: PR #11361 One bug is currently there in the algorithm, which can be fixed since we have to make assignments to $\tau$. Also currently no tests have been added, which can be added.
  • Rewriting System: This can be a good candidate for a major work, I included this topic in my proposal though was left untouched. Perhaps GAP could be first seen in this regard. Like always
  • Groups folder: After a few of the above mentioned things have been done, I believe it could be a good time to make a folder named groups, since finitely presented groups should not be a part of combinatorics module which would contain the all algebraic structures including the permutation groups.
  • Non-associative algebra: (Perhaps I got the spelling of associative this time right!) Albert CAS could be used to understand the workings related to non-associative algebra, it contains quite good functionalities.

Things I did right/wrong

  • I often lagged in writing blogs.
  • I worked more than expected hours before 15 July (before college started) but much less in the last one month of GSoC because of a little busy schedule.


I had say that I did about 70% of the work I promised to do in my proposal, considering that I also did two non-included task of Low Index subgroups algorithm and Modified Todd Coxeter algorithm, so I can say I swapped my work. It is good enough, and I hope to get back to extending the things that I have started. There's still some revision to be made, some code to be clean up. And I'm doing that.

I don't really know if I'll pass final evaluations by Google, but, regardless, I'm really glad for all the coding and development experience I got during these weeks. I'll probably use for personal projects, may be in Dissertation in last year, and try to contribute more to SymPy.

I appreciate the help of my mentor Kalevi Suominen who was always there for any query that I had regarding Group Theory in project, and I appreciate his ability to reply back within 1 hour for any message I left any time of day and every day of the week including weekend (I call it 1-hour rule). I think he was a wonderful mentor and I learnt a lot from him, and my co-mentor Aaron Meurer, the current project leader of SymPy, and the entire SymPy community for helping me out and reviewing my work!

Also thank you Google.

अलविदा !

August 20, 2016


This week I started work on polynomial factorization in Z. I implemented the zassenhaus’s algorithm, which factors a primitive square-free polynomial.
The basic idea behind factoring a polynomial in Z is first to make it square free using Yun's algorithm or something similar and then choosing a prime number p, such that the polynomial mod p is square free, and p doesn’t divide its leading coefficient. After that it is reduced to factoring polynomial in finite field. Which has already been implemented, then we lift all the factors from the finite field to Z using hensel lifting.
The number of time Hensel Lifting has to be done is found using the Mignotte’s bound.
This wall required implementation of extended euclidean GCD in the finite fields. So, after the implementation of factorization of square free algorithms, we were able to perform:

f = UIntPoly::from_vec(x, {1_z, 0_z, -9_z});
// f = -9x**2 + 1
out = f->zz_zassenhaus();
// out is a set of RCP<const UIntPoly>
// out = {-3x + 1, -3x - 1}
out_f = f->zz_factor_sqf();
// out_f is a pair<integer_class, std::set<RCP<const UIntPoly>>
// out_.f.first = 1
// out_f. second = {3x + 1, 3x - 1}

After this I need to implement the algorithm for square free factorization and the trial division for finding the power of factor in the polynomial, this way we will be able to factor the polynomials. The PR is here.

Documentation nonlinsolve:

PR #11532

Conclusion :

So the GSoC coding period is going to end. Here I am writing what I did, my todo list and suggestions for future work.

Meanwhile :

  • I find one issue : #11534 in mailing list discussion. This shows that we need better invert method for inverting nested roots/powers equtions in solveset .

  • and this #11528. factor_list will be helpful in factoring the equation in solveset and solve for it factors and union the solution(during the PR #11188 discussion with Harsh this idea came out). It will actually replace the elif f.is_Mul and all(_is_finite_with_finite_vars(m, domain) statement in _solveset and factor_list will be used soon.

August 19, 2016

Hello all! This is officially the last week for Google Summer of Code 2016. The submission and final evaluation has already started. Last week I was busy with fixing bugs and preparing documentation for the beam module.

The things that I have implemented till now

  • DiracDelta can be represented in piecewise form.
  • DiracDelta and Heaviside have a detailed docstring.
  • DiracDelta can be pretty printed using δ(x).
  • Singularity Function module which can perform all sort of mathematical operations on discontinuity functions.
  • Beam module which can solve 2D beam bending problems.

Future Plans

Jason has came up with some new ideas for beam module:

  • Plot the shear, bending, slope and deflection diagrams..
  • Compute the strain and stress at any location in the beam.
  • Improve the beam module for more complicated loads.

I have planed for a long term association with SymPy, I am taking the full responsibilty of my code and I will try to contribute as much as I can. I will help the new developers with the Sympy code paradigms and the development workflow.

I have been able to meet all the target that I had mentioned in my proposal and all of my pull requests have got merged except PR 11494. It was great working with Sympy. Jason, Sartaj, Aaron, Kalevi, Isuru and all other sympy members have helped me a lot. Many of the times, I used to get stuck with some implementation, testing or with the Travis CI build but, for everytime they have always tried to help me fix them. My mentors have always appreciated and motivated me. I got to learn many new thing about the software development workflow. Thank you Sympy for making this summer an awesome journey of learning and coding.

That’s all folks.

Happy Coding.


For the duration of GSoC, I have worked on the SymEngine project, with focus on writing the Cwrapper and specifically the Ruby Wrapper. Major work during the project timeline included wrapping already existing features such as MPC, MPFR, arbitrary precision evaluations, Matrices, expression parsing etc., and new features such as lambdifying expressions in Ruby and Exception Handling.


My proposal for GSoC 2016 can be viewed here [1].

Progress Report:

After 13 weeks of GSoC, we’re now at the end of the summer, and it is time for me to explain and report what I did with SymEngine and its Ruby Wrappers throughout the summer.

For reporting purposes, I will take each week’s workload and indicate the status in a tabular manner, with links to the relevant PRs. Due to the nature of the project, each part usually consists of two PRs. One to the SymEngine repository [2], and the other to the SymEngine.rb [3] repository.

Week Work SymEngine SymEngine.RB Comments
1, 2 Complex Numbers & Floating Points Completed

Wrappers for Real Double: PR#954

Implementing real_double_get_d method: PR#966

Wrappers for Real MPFR and Complex MPC: PR#972

fixes #974: PR#975


Real Double Class: PR#46

Ruby Wrappers for Real MPFR and Complex MPC: PR#49

3 Derivatives, Substitutions, Abs Completed

Function symbol Cwrappers: PR#982


Abs: PR#50

Function symbol Ruby Wrappers: PR#51

3 Series & Polynomials The relevant parts in SymEngine’s C++ code library was not ready, so I had to skip this part.
3 Evalf Completed

Common evals method and its Cwrappers: PR#987

Sign check for Numbers: PR#1027


evalf ruby wrapper: PR#55

This was not included in the original proposal. Completed to compensate for Series and Polynomials.
4, 5, 6 Matrices Completed.

Matrix Cwrappers: PR#992

PR Under Review.

Matrix Ruby Wrappers: PR#56

7 Parser Completed

CWrapper for parser: PR#1029


Ruby wrapper for parser: PR#60

Awaiting merging.
8 Lambdify N/A Completed

Lambdify as a module level function: PR#61

All work was performed on Ruby Wrappers directly.
9, 10 Exception Handling Completed

Exception Handling: PR#1044

Fixing enum issue in Exceptions: PR#1069


Exception Handling: PR#64

Wiki on exception handling. [4]
11 Interfacing with GMP, MPFR, MPC gems Incomplete Incomplete
12 Buffer Period N/A N/A Allocated time to catch up with missed work.
13 Iruby Notebooks N/A Awaiting Merging
Changes to beginner notebook:
Although the examples are ready, and were included in SymEngine’s presentation at SciPy [5], they were not merged, pending improvements to the formatting.

Other PRs:

The following PRs were made for minor contributions.

Summary of Merged Contributions:

  • On SymEngine/SymEngine Repository:
106 commits / 4,316 ++ / 1,928 —

  • On SymEngine/SymEngine.RB Repository:
134 commits / 3,756 ++ / 1,319 —


This is the final week of GSoC! I have the write up of the work done on a different page.

This project has been a wonderful learning experience and I have met many wonderful people over the course of this summer. Before the summer began I had never written any test code. Now at the conclusion of the summer I have written benchmark tests and I try to make sure the code I write has complete unit coverage. I feel that this is one of my biggest areas of improvement over the past 3 months. I have also learned a considerable amount about the combination of programming and dynamics. Prior to GSoC my experience with dynamics consisted solely of finding the equations of motion by hand. With my time in GSoC I have been exposed to finding the equations of motion programatically and using the results with an ode integrator. I have also obtained a more in depth knowledge of different algorithms for creating the equations of motion.

Another thing that I have enjoyed in this experience is seeing how a large programming project works. I feel that this will make me more employable in the future as well as allow me to help any other new open source community get up and running.

Lastly, one of the big highlights of my summer was my trip to Austin, TX for Scipy 2016. Being a GSoC student I not only got to go to my first professional conference but I was able to help give one of the tutorials. Also I was able to meet many of the other people who work on sympy. This went a long way in making my contributions to sympy from being just contributions to some organization to working on a project with other people. It was also neat to meet the developers of other open source projects. Like my comment about sympy, I now see those projects less as being “project name” and more as the people actually working on them.

I have enjoyed my GSoC experience and if I were eligible I would not hesitate to apply again. I would like to thank those who chose me and made this summer of learning and experiences possible.

August 16, 2016


After the last blog post, I started working on the “fixing up the remainder of rational polynomials”. This also included adding support for basic to rational polynomial conversions. The current work is in #1055 which has not been merged in yet.

Another thing I started working on was conversions from SymEngine symbolics to multivariate polynomials. The way the current conversions work, led me to change the overall structure of multivariate polynomials.

Restructuring Multivariate Polynomials

The current working of basic conversions is that it constructs the “internal container” of the polynomial as it parses the expression. These containers have operators overloaded and they can easily be manipulated by the functions. Handling multivariate polynomials using this approach would be impossible with the current structure of the code. There were no “containers” per se in the previous implementation.

I thought it would be better if we can implement a container based polynomial structure for multivariate polynomials too. Fortunately, the way the SymEngine polynomials work, an approach similar to the univariate case of containers worked. The container is a wrapper around a map from vector to a value (the coefficient)

template <typename Vec, typename Value, typename Wrapper>
class UDictWrapper
    using Dict = std::unordered_map<Vec, Value, vec_hash<Vec>>;
    Dict dict_;
    unsigned int vec_size;


The polynomial class uses this as a container, along with information about the generators and their ordering. Apart from holding the map, this class has various constructors, and all the operators overloaded for it. It also has helper functions, which help translate the current keys to another specific order/ arrangement. The container assumes that the all operations done to it are with other “adjusted” containers. Currently, the job of adjusting/aligning th container has been delegated to functions like add_mpoly etc.

template <typename Poly>
RCP<const Poly> add_mpoly(const Poly &a, const Poly &b)
    typename Poly::container_type x, y;
    set_basic s = get_translated_container(x, y, a, b);
    x += y;
    return Poly::from_container(s, std::move(x));


template <typename Poly, typename Container>
set_basic get_translated_container(Container &x, Container &y,
                                   const Poly &a, const Poly &b)
    vec_uint v1, v2;
    set_basic s;

    unsigned int sz = reconcile(v1, v2, s, a.vars_, b.vars_);
    x = a.poly_.translate(v1, sz);
    y = b.poly_.translate(v2, sz);

    return s;

Basically, both the containers get the ordering of generators in the “new” polynomial which will soon be constructed, and adjust the ordering of the vectors inside their maps accordingly. Thus consistency is maintained. All the work done is in #1049 and this has been merged in.

Remaining work

  • After getting this restructure done, I started work on the basic to multivariate conversions, though I have not been able to cover it completely. The idea for these conversions remains the same and should be easy to implement.

  • I also could not spend time to integrate wrappers to Piranha polynomials which can be used as multivariate polynomials within SymEngine

Wrapping up GSoC

This is officially the last week of Google Summer of Code ‘16. Although GSoC is over, I plan to get the above mentioned work finished within August, before any other big undertaking. It has been a wonderful journey of insight and knowledge. Thanks a lot to my mentors Isuru, Ondrej and Sumith for helping me throughout the summers, and always being there for discussions and the silly issues I bombarded them with!


August 15, 2016

nonlinsolve continue:

  • PR : #11111

  • few things that should be improved in nonlinsolve :

    - If system of equation contains trigonometric functions, `nonlinsolve`
    sometime fails because `solve_trig` of `solveset` is not much better and
    `nonlinsolve` have to identify what is the Intersection soln when we have
    `2*n*pi + pi/2` and `n*pi + pi/2`(means something similar cases).Right now it is returning
    one of them.
    - `substitution` function which solves the system of equation using substitution method.
    There should be better method to handle `imageset` (Complex solution).
    - Code quality of `substitution` should be improved.

Continue Simplified Trig soln

  • PR #11188

  • Imageset/union is generalized and now it handle basically these three cases:

# img1 = ImageSet(Lambda(n, a*n + b), S.Integers)
# img2 = ImageSet(Lambda(n, c*n + d), S.Integers)
In [1]: img1 = ImageSet(Lambda(n, 4*n + 4), S.Integers)

In [2]: img2 = ImageSet(Lambda(n, 4*n), S.Integers)
# when a == c and (b - d == a) then ans is img2.
In [3]: Union(img1, img2)
Out[3]: {4⋅n | n ∊ ℤ}

# -------------------------------------------------------------

In [4]: img1 = ImageSet(Lambda(n, 4*n + 2), S.Integers)
# when a == c and (b - d) == a/2, means value is  a/2 * n
In [5]: Union(img1, img2)
Out[5]: {2⋅n | n ∊ ℤ}

# -------------------------------------------------------------

# 5*n + 5/4 ==> 5*n + 1 + 1/4
# 5*n + 1 + 1/4 is in n + 1/4
# check using img1.superset(img2) == true so img1 in ans
img1 = ImageSet(Lambda(n, n + S(1)/4 ), S.Integers)
img2 = ImageSet(Lambda(n, 5*n + S(5)/4 ), S.Integers)

In [4]: Union(img1, img2)
Out[4]: {n + 1/4 | n ∊ ℤ}

# -------------------------------------------------------------

# img1.issuperset(img2) is false so no change
img1 = ImageSet(Lambda(n, 2*n + S(1)/4 ), S.Integers)
img2 = ImageSet(Lambda(n, 5*n +S(5)/4), S.Integers)
In [5]: Union(img1, img2)
Out[5]: {2⋅n + 1/4 | n ∊ ℤ} ∪ {5⋅n + 5/4 | n ∊ ℤ}

Meanwhile :

  • I found some more cases where factor_list fails and opened a PR :


August 12, 2016

This week I spent a lot of time working on FeatherstonesMethod and its component parts. I started off by moving a bunch of spatial vector functions from another PR I have to the featherstone PR and used some of those functions to calculate the spatial inertia of Body objects. The next thing I worked on was completely rewriting the internals of the joint code. The joints now consist of 4 reference frames and points (one set at each of the bodys mass centers and one set per body at the joint location).

After this I ran some basic code that used these new features and kept making changes until the code was able to run without producing errors. I used this same method of work with FeatherstonesMethod and now it too is able to run without producing errors. Now that the code runs it was time to make sure that the output is correct which is a lot more involved than the previous step of work. To begin I solved for the spatial inertia by hand and used this calculation to create test code for Body.spatial_inertia. As expected the code initially was completely incorrect but it now passes the test. I have since been working on the tests for the joint code. Since this code is completely new to the sympy repository it takes a lot more planning than the body test did. Also I need to solve the kinematics by hand for the joints so that I have a base for the test code. This is where I am currently located in the process.

Also this week I addressed review comments on SymbolicSystem and have moved that PR closer to being able to merge. One of the current hang ups is trying to force Sphinx to autodocument the __init__ method. I think the best solution currently is to move the relevant code back to the main docstring for the class and not worry about trying to document the __init__ method.

While working on rewriting the joint code I came across a bug in and have created a docstring with a fix to this along with a test to make sure the fix works.

Lastly I reviewed a PR that adds a docstring to a method that did not yet have a docstring. The PR had some information in it that was incorrect and after some research I was able to make some suggestions for its implementation.

Future Directions

Next week is the last full week of GSoC and my main priority is getting the final evaluation information correctly finished so that the work can be processed correctly. My next goal is to make sure SymbolicSystem gets merged into SymPy. This is not entirely in my hands, however, as I will be having to wait for feedback and so while waiting I will be pulling off different parts of FeatherstonesMethod for separate PR’s at the recomendation of my advisor. These separate PR’s I hope to possibly include in my final evaluation.

PR’s and Issues

  • (Open) [WIP] Added to physics/mechanics PR #11431
  • (Open) [WIP] FeatherstonesMethod PR #11415
  • (Open) Added docstring to jordan_cell method PR #10356

August 11, 2016


This week I worked on little refactoring of Fields module. Like moving functions implementations from .h file to .cpp file in this PR. I added a from_uintpoly method which allows us to create a GaloisField object from UIntPoly object in this PR. After which I worked on the implementation of diff method for GaloisField in this PR.
Then I worked on Logic module. It is needed for the implementation of Intersection class in Sets module. It has the implementation for Logical And, Or and Not operations.
Both Or and And class have a private variable named container_ which is a set of RCP<const Boolean>. It stores the Boolean objects on which And and Or operator can’t be applied using the known rules.
Not also has one private variable which is an RCB<const Boolean> object, which stores the Boolean object on which we were not able to apply not operator using the current rules.
Then we have three functions:

RCP<const Boolean> logical_and(const set_boolean &s);
RCP<const Boolean> logical_or(const set_boolean &s);
RCP<const Boolean> logical_not(const RCP<const Boolean> &s);

These are used to do the respective operation on the operands supplied.
Talking little about implementaion details:

RCP<const Boolean> logical_and(const set_boolean &s)
   return and_or<And>(s, false);

RCP<const Boolean> logical_or(const set_boolean &s)
   return and_or<Or>(s, true);

And the function and_or do the required operations.
After this PR gets merged, I would start working on Intersection class.

August 09, 2016

Hi all, here's a brief summary of the 12th week of my GSoC:
Last week I uploaded the test-coverage files on my website, that revealed some interesting places where a few versions of scan routine in coset enumeration have un-tested if-elif-else case.

As we are now approaching the end of GSoC time period, we decided to do some testing with some of the examples from 1973cdhw paper [2]. Coset Enumeration got my attention again since:

There seemed to be one bug raising TypeError so opened issue sympy/sympy/#11449, resulting from coset enumeration by the coset-table based method. From beginning it was clear that the issue was not in compress() method. It was quite difficult for me get onto the main source of problem. But then Kalevi had a closer look on the pseudo-code in Derek Holt and also in Sims Finitely Presented Groups.

I wrote docstrings for a few of methods and fixed the issue #11449 in PR #11460.

The problem there in code is explained briefly below

Previous code-snippet

1    i = 0
2    while i < len(
3        alpha =[i]
4        i += 1
5        for x in C.A:
6            if C.table[alpha][C.A_dict[x]] is None:
7                C.define_f(alpha, x)
8                C.process_deductions(R_c_list[C.A_dict[x]], R_c_list[C.A_dict_inv[x]])

After code-snippet

1     while alpha < len(C.table):
2         if C.p[alpha] == alpha:
3             for x in C.A:
4                 if C.p[alpha] != alpha:
5                     break
6                 if C.table[alpha][C.A_dict[x]] is None:
7                    C.define_c(alpha, x)
8                     C.process_deductions(R_c_list[C.A_dict[x]], R_c_list[C.A_dict_inv[x]])

Here $\alpha$ looks over in till $\lt$ C.table. This way all elements of $C.\Omega$ are tested even in case that the set becomes very small. The inner for $x$ loop should also tests $p[i]$ at each round and break if that becomes different from $i$.

The changes that have been addressed in PR #11460 also include chaging the file name to, similar to what we have.

It seems that Presentation of Permutation Groups won't happen during GSoC since there's just one more week; instead, I plan to focus on improving and completing the current PR's #11361 on Modified Todd-Coxeter algorithm and PR #11460 on addition of docstrings and better user methods.

One more thing, that I would start in this week though may not be completed this week will be the sphinx documentation of finitely presented groups. I found the documentation of Poly's module by Kalevi very much readable and interesting, may be I can seek to follow that.


August 08, 2016

This week I primarily worked on some bugs and added singular initial conditions to the result of expr_to_holonomic().

Firstly I fixed a bug in .unify(). There were some errors being raised in it when one of the Holonomic Function had ground domain RR or an extension of it. This now works fine.

In [9]: expr_to_holonomic(1.4*x)*expr_to_holonomic(a*x, x)
Out[9]: HolonomicFunction((-2.0) + (1.0*x)*Dx, x, 0, {2: [1.4*a]})

In [10]: _9.to_expr()

Later I fixed a bug in converting the two types of initial condition into one another. Apparently I forgot to add the factorial term while converting.

After that I added singular initial conditions to the result of expr_to_holonomic()  whenever the Indicial equation have one root. For example:

In [14]: expr_to_holonomic(x*exp(x))
Out[14]: HolonomicFunction((-x - 1) + (x)*Dx, x, 0, {1: [1]})

In [15]: _.to_expr()

I also changed printing of the class HolonomicFunction to include the initial conditions inside the call, so as to make it proper python. These are implemented in #11480 and #11451.

Right now we are trying to find a way to include convergence conditions in the result while converting Holonomic Functions to expressions.

August 07, 2016

During the past couple of weeks, I worked on replacing solve with solveset in solving inequalities.


SymPy’s univariate inequality solver, solve_univariate_inequality relies on solve for reducing inequalities.

In[] : isolve = solve_univariate_inequality # for simplicity

As we would prefer using solveset internally, it is important to remove the dependency on solve here. However, there are a lot of issues which need to be handled carefully. Here are a few of them:

  1. The major issue with using solveset is the Set output API. As isolve is designed to work according to solve’s results, this seems to be the roadblock.

  2. No support for restricted domain.

    Generally, the inequalties are solved in the entire real domain. However, this might not be what the user want (especially while dealing with trigonometric inequalties). Also, to maintain uniformity across all our solvers, support for user-speicifed domain is a must.

  3. Incorrect results for trigonometric inequalties

    As Issue #9721, isolve returns incorrect results for certain trigonometric inequalities.

  In []: isolve(cos(x) > 0, x, relational=False)
  Out[]: (-oo, pi/2)

  In []: isolve(tan(x) > 0, x, relational=False)
  Out[]: (0, oo)


  1. Implementing solvify : “solve”-fy solveset’s solutions.
    There were two possible ways to tackle the issue of APIs:

    a. Refactoring isolve in according with Set API.

    b. Somehow returning solve results from solveset.

    Solution : b

    In order to resolve the issue of portability from solve to solveset, I implemented solvify which returns solve-like results. We classify the return value based on the type of solution returned by solveset.

    Solution | Output —————————————- FiniteSet | list

    ImageSet, list (if f is periodic)
    EmptySet empty list
    Others None
  2. Adding domain support.

    I added a domain argument to isolve whose default value is the real domain (domain=S.Reals). A few limitation to the conditions of S.Infinity and S.NegativeInfinity followed.

    Another noticable point, from the point of implementation, was to deal with singularities and discontinuities of the given inequality. For this, I used the continuous_domain method to find the continuous domains of the expression within the specified domain.

    This was a minimalistic addition with considerable returns (especially for solving periodic inequalties).

  3. Solving trigonometric inequalities.

    Since most of the trigonometric inequalities are periodic in nature and have infinite solutions, solving the expression in the entire real domain is a repetitive task and computationally expensive.

    In order to simplify the problem, I intend to solve all the inequalities in a positive periodic interval (say [0, 2*pi) for sin(x)). We already have a function to compute the real period of a function : periodicity.
    In case of a non-finite domain argument, I intend to use this to restrict the solutions of the problem to a periodic interval.

    This might not seem the perfect approach but it seems reasonable to handle infinite interval sets for now. We need a new Set object : BigUnion to represent infinite number of interval objects.

New Implementation

I have opened PR#11458 for the same with all the implementation details.

In []: isolve(cos(x) > S(0), x, relational=False)
Out[]: [0, pi/2) U (3*pi/2, 2*pi)

In []: isolve(tan(x) > S(0), x, relational=False)
Out[]: (0, pi/2)

After thoughts

For the past couple of weeks, I haven’t been able to give much time to the project due to my college schedule. I try to make up for the lost time during the weekend and meet the 40 hour weekly deadline.

With the endsem evaluation soon approaching, I expect this PR to get merged and count as a part of my project.

eliminate() continue:

  • PR : #11485

  • Regarding issue #2720, It is something similar to eliminate present in wolfram.

  • Right now it is working for real domain and not considering ImageSet, Intersection. Complement. If it find ImageSet, Intersection. Complement for the symbol to be eliminated, then just raises NotImaplementedError(in near future it can be implemented).

  • It can take N nummber of equations and M number of symbols to be eliminated. It returns FiniteSet of equations which doesn’t contains these symbols.

Continue - Diophantine in Solveset :

PR 11234

  • In commit : returning ConditionSet when it diophantine doesn’t the diophantine equation type and not able to solve.

Idea for improved _solve_trig in Solveset :

In [1]: solveset(sin(x) + cos(y), x, S.Reals)
Out[1]: {x | x ∊ ℝ ∧ sin(x) + cos(y) = 0}

In [2]: solve(sin(x) + cos(y), x)
Out[2]: [asin(cos(y)) + π, -asin(cos(y))]

  • This above examples is enough to tell that _solve_trig is not using inverse trigonometric function. We can have something, which can solve trig equations by making free the symbol in lhs and in rhs inverse trig function.

  • solveset(sin(2*x) - sqrt(3)*cos(2*x), x, S.Reals) for this right now _solve_trig is converting it into exp form and solving it. But it is can be simply solved using sin(x + y) == sin(x)*cos(y) + cos(x)*sin(y) formula.

  • First divide both side with sqrt(a**2 + b**2) where a, b is coeff of sin(2*x) , cos(2*x).

  • sin(2*x)/2 - (sqrt(3)/2)*cos(2*x) ==> sin(2*x)*cos(pi/3) - sin(pi/3)*cos(2*x) ==> sin(2*x - pi/3).

  • Now sin(2*x - pi/3) is solvable using solve_decomposition.

Meanwhile :

  • Some analysis about Abs solver :

In [1]: solveset(Abs(x) - 1,  x)
Absolute values cannot be inverted in the complex domain.

In [2]: solveset(Abs(x) - (1 + I), x)
Absolute values cannot be inverted in the complex domain.

In [3]: solveset(Abs(x) - y , x)

Absolute values cannot be inverted in the complex domain. - In 1st case (for complex domain) ans should be

  • In 2nd case EmptySet. and in 3rd case (general solution when domain=S.Complexes) soln should be

  • In general( 3rd case) it should print ConditionSet(x, -Abs(re(y)) <= re(x) and re(x) <= Abs(re(y)) and re(y)>0, Eq(im(y), 0) , S.Complexes).


August 06, 2016

Hi there! It’s been eleven weeks into GSoC . The module for solving beam bending problems is almost ready. Now, I am focusing fully on example documentation part because it’s very important to let others know what can be done.

So Far

Let us see the capabilities:-

  • Can create a beam object of certain length, second moment of area and modulus of elasticity. A symbol can also be passed for further uses.
  • Can apply loads using its value, start, end and order.
  • Can set boundary conditions for the beam.
  • Can find the load distribution function.
  • Can find the shear force function.
  • Can find the bending moment function.
  • Can find the slope function.
  • Can find the deflection function.
  • Can represent each of those function in the Piecewise form.
  • Can perform all sorts of mathematical operations on these functions.

A full fledged documentation of tutorial and example for this module is on its way.

Next Week

  • To complete documenting examples and tutorials.
  • Get PR 11374 merged.

That’s all for now, looking forward for week 12.

Happy Coding.

August 05, 2016

This week my main work was on Featherstone’s articulated body algorithm. I started by prototyping what I thought his algorith might look like in python code (the algorithm was pulled from chapter 7 of his book). With the passes prototyped it was apparent that I would need a full description of the kinematic tree and so I prototyped the building of the kinematic tree from a single “base” body. I then went on to see what it would look like if the kinematic tree was built during the first pass of his articulated body algorithm and decided that keeping the two separate would result in cleaner code.

With the three passes prototyped and the kinematic tree built I started digging into Featherstone’s book to better determine the definition of each of the variables in the algorithm. While doing this I ended up reading a second source where Featherstone describes the articulated body algorithm and it was helpful in furthering my understanding of the algorithm as it was a condensed summary. I then compared the written version of the algorith in his book and this article with the two matlab versions he has posted online and the python version her provides a link for online. This helped me see where some terms he includes in his book he doesn’t include in his code. It also helped me to see what code for the algorithm might look like.

After working on the mock up of the passes and trying to better understand them, I switched focus to the joint code that needs to be finished so that it can be used in my implementation of the articulated body algorithm. This has lead to some confusion about the design decisions that were made in the past when putting together the joint code and this is the current stage I am sitting at as I await feedback on some of my questions.

This week I also looked over a couple of documentation PR’s. One was a simple matter of fixing some indentation and seems mostly ready to merge but the second turned some docstrings into raw strings so they could add latex math code. I don’t know what the general stance is on the latter but I’m of the opinion that the docstrings should be human readable since people may actually look through the code for them or hope that help(function) provides something useful. In this case the latex math code is cluttered and would be better off in .rst files where people are only going to be reading the rendered version. On that PR I am awaiting response from someone with sympy to see if this is indeed prefered.

Future Directions

Hopefully I’ll recieve some feedback about the joints and Featherstone’s method so I can keep moving forward with these. In the mean time there are a few other bits of code I will need to complete that the algorithm uses that is not directly related to my questions. If I finish these tasks before recieving feedback I will move forward with changing the joint code as I think would be best.

PR’s and Issues

  • (Open) [WIP] Added to physics/mechanics PR #11431
  • (Open) Intendation fixes – sympy/concrete/ PR #11473
  • (Open) Adjustments to Legendre, Jacobi symbols docstrings PR #11474
  • (Open) [WIP] FeatherstonesMethod PR #11415


This week, I had been working on implementaion of Union and Contains in this PR.
Our Set::contains function has been changed from :

virtual bool contains(const RCP<const Basic> &a) const = 0;


virtual RCP<const Boolean> contains(const RCP<const Basic> &a) const = 0;

And these functions:

virtual bool is_subset(const RCP<const Set> &o) const = 0;
virtual bool is_proper_subset(const RCP<const Set> &o) const = 0;
virtual bool is_superset(const RCP<const Set> &o) const = 0;
virtual bool is_proper_superset(const RCP<const Set> &o) const = 0;

have been changed to:

bool is_subset(const RCP<const Set> &o) const
    return eq(*this->set_intersection(o), *this);
bool is_proper_subset(const RCP<const Set> &o) const
    return not eq(*this, *o) and this->is_subset(o);
bool is_superset(const RCP<const Set> &o) const
    return o->is_subset(rcp_from_this_cast<const Set>());
bool is_proper_superset(const RCP<const Set> &o) const
    return not eq(*this, *o) and this->is_superset(o);

depending solely on set_intersection.

Then the SymEngine::set_union(const set_set &in, bool solve = true) has been defined which will create a Union object with in if it is not solvable, or will do union operation on all of them.
Our Union class has std::set of Set to store the different Set containers which can’t be unified into one single container.
Apart from it, the set_intersection ans set_union virtual functions have been restructured to handle other Set types case by case.

August 01, 2016

Started off this week by continuing my work on #11422. I added support for singular initial conditions in multiplication and made some amendments in addition too. They now can return a Holonomic function with singular initial condition. The input functions can have singular initial condition both or one of them can have singular one and the other one with ordinary initial condition.

# one function have singular initial condition and the other have ordinary.
In [4]: expr_to_holonomic(x) + expr_to_holonomic(sqrt(x))
Out[4]: HolonomicFunction((1/2) + (-x/2)Dx + (x**2)Dx**2, x), {1/2: [1], 1: [1]}

In [5]: _4.to_expr()
Out[5]: √x + x

In [6]: expr_to_holonomic(x) * expr_to_holonomic(sqrt(x))
Out[6]: HolonomicFunction((-3/2) + (x)Dx, x), {3/2: [1]}

In [7]: _6.to_expr()

# both have singular initial conditions.
In [9]: expr_to_holonomic((x)**(S(1)/3)) + expr_to_holonomic(sqrt(x))
Out[9]: HolonomicFunction((1/6) + (x/6)Dx + (x**2)Dx**2, x), {1/3: [1], 1/2: [1]}

In [10]: _9.to_expr()
3 ___
╲╱ x  + √x
In [11]: expr_to_holonomic((x)**(S(1)/3))*expr_to_holonomic(sqrt(x))
Out[11]: HolonomicFunction((-5/6) + (x)Dx, x), {5/6: [1]}

In [12]: _11.to_expr()

I found some problems in coding because of storing these initial conditions in two different attributes. So I merged them to a single attribute and instead added methods to check which one is stored and refactored the existing code using it.

I opened a new PR #11451 majorly focused on adding singular initial conditions to the result of .expr_to_holonomic() when necessary. At first I added it in converting polynomials. Here are some examples:

In [14]: expr_to_holonomic(3*x**3+4*x**2)
Out[14]: HolonomicFunction((-9*x - 8) + (3*x**2 + 4*x)Dx, x), {2: [4, 3]}

In [15]: _14.to_expr()
x ⋅(3⋅x + 4)

In [16]: expr_to_holonomic(x)
Out[16]: HolonomicFunction((-1) + (x)Dx, x), {1: [1]}

In [17]: _16.to_expr()
Out[17]: x

I also a found a bug in .to_hyper() when the recurrence relation has order 0. Added its fix too. Earlier the output also considered negative exponents which weren’t needed.

# previously
In [18]: expr_to_holonomic(y*x, x).integrate(x).to_expr()
x ⋅y
──── + C₁
# after fix
In [19]: expr_to_holonomic(y*x, x).integrate(x).to_expr()
x ⋅y

What Next:

I hope to add singular initial conditions to more types of functions in .expr_to_holonomic().


After college has started, work has been slower than usual. Last week I finally wound up Rational Polynomials in #1028. Some minor changes still remain in some parts of the code. Most of the changes left are mainly related to code duplication, and will be fixed by writing their templated versions.

Multivariate Polynomials

I started off by reading and understanding how the multivariate class is implemented currently in SymEngine. It was developed by the UC Davis team as a part of their course project. The basic idea is pretty simple. It still is a sparse representation and maps from a vector (representing the powers of each generator in the monomial) to the non-zero coefficient multiplied to it. We use an unordered map instead of the ordered map used in the univariate counterpart. The choice does make some sense, as deciding order between two monomials is subjective and does not make sense (for eg. which is larger x**2*y or x*y**2) Even if we define a custom ordering, there are no real benefits I could think of that it would provide.

On a side note, it kind of makes me think why we have stuck to the ordered map implementation for our univariate polynomials. The places it offers benefits are eval and mul (in some ways) I worked with ordered maps, as that was the implementation the initial polynomial class was built on. I’m also wondering if it is healthy to use two different implementations for both the polynomial types, univariate and multivariate. This needs to be discussed.

Right now, I’m basically refactoring most of the code written in the multivariate class, so that it matches the API more or less from the univariate case. Some functions have been re-written and some unnecessary storage within the polynomials have been removed. Initially, I thought I will stick with the same container based approach I used in the univariate case. This proves to be non trivial for the multivariate case. So, after some discussion with Isuru, we decided to stick with different implementations for SymEngine polynomials and Piranha polynomials, as combining code was not easy. The current work is in #1049

Future Work

A lot is on my plate right now. Some of the work I plan to finish by the end of the next two weeks are

  • Finish up the refactoring of multivariate polynomials, and make their interaction with univariate polynomials as seamless as possible

  • Introduce wrappers for piranha polynomials to be used as multivariate polynomials within SymEngine

  • Fix up the remainder of rational polynomials, and template code wherever possible to remove code duplicates

  • Write conversions from Basic to multivariate polynomials, which will finish up one part of the coercion framework as proposed by Isuru

Off to work!

July 30, 2016

eliminate() continue:

Output of solveset should be of one type:

  • Amit discussed about it. Solution we see in solveset should be in one type of set. Right now we may have solution in Imageset, Finiteset, Complement, Intersection or ConditionSet. So there would be problem for user to handle these many solution type.

  • I think there should be something that separate Complements, Intersections,ConditionSet and main solution in Finiteset.

  • E.g. if solveset solution is Intersection(Complement(FiniteSet(x), {y}), {z}) then soln : FiniteSet(x), x != {y}, {x} intersect {z}.

Continue Simplified Trig soln

PR #11188

  • According to the Harsh comments/review I modified the PR. Now it seems it is returning more simplified solution( one case is here) .

  • To understand the changes I did in the _solve_trig method, one should check this gist

  • To see the advantage of imageset union, One good example is in this gist


July 29, 2016

Hello, guys. Welcome back. It’s been ten weeks into the coding period. I had a meeting with Jason on 25th of this month. We discussed many new changed on the API that I had implemented before this week. Now, the beam bending module is almost ready to solve beam bending problems.

Let us see how to solve a beam bending problem using this module.

Problem Statement :

Loaded beam.svg

The deflection is restricted at the end of the beam.

Solution :

>>> from sympy.physics.continuum_mechanics.beam import Beam

>>> from sympy import Symbol, Piecewise
>>> x = Symbol('x')

>>> E = Symbol('E')

>>> I = Symbol('I')

>>> b = Beam(4, E, I)

>>> b.apply_load(value=-9, start=4, order=-1)

>>> b.apply_load(value=-3, start=0, order=-1)

>>> b.apply_load(order=0, start=2, value=6)

>>> b.bc_deflection = [(4, 0)]

>>> b.boundary_conditions
 {'deflection': [(4, 0)], 'moment': [], 'slope': []}

>>> b.load
 -3*SingularityFunction(x, 0, -1) + 6*SingularityFunction(x, 2, 0) - 9*SingularityFunction(x, 4, -1)

>>> b.shear_force()
 -3*SingularityFunction(x, 0, 0) + 6*SingularityFunction(x, 2, 1) - 9*SingularityFunction(x, 4, 0)

>>> b.bending_moment()
 3*SingularityFunction(x, 0, 1) - 3*SingularityFunction(x, 2, 2) + 9*SingularityFunction(x, 4, 1)

>>> b.slope()
 (3*SingularityFunction(x, 0, 2)/2 - SingularityFunction(x, 2, 3) + 9*SingularityFunction(x, 4, 2)/2 - 7)/(E*I)

>>> b.deflection()
 (-7*x + SingularityFunction(x, 0, 3)/2 - SingularityFunction(x, 2, 4)/4 + 3*SingularityFunction(x, 4, 3)/2)/(E*I)

If the user wants to represent the deflection in the piecewise form, then:

>>> b.deflection().rewrite(Piecewise)
 (-7*x + Piecewise((x**3, x > 0), (0, True))/2
 + 3*Piecewise(((x - 4)**3, x - 4 > 0), (0, True))/2
 - Piecewise(((x - 2)**4, x - 2 > 0), (0, True))/4)/(E*I)


Next week

  • Add the end argument in the apply_load method.
  • Add Sphinx documentations.

That’s all for this week. Cheers !!

Happy Coding.

Somehow I think I was off by a week. I think last week’s blog post covers week 9 and 10 and this week’s covers week 11. This week I created a full draft for all components of the SymbolicSystem class that will take the place of a equations of motion generator “base class” that was discussed in my project proposal. I began by creating all of the docstrings for the class followed by the test code. With the documentation and test code written it was a simple matter to finish off the code for the class itself. Lastly I added documentation to two places in sympy, one place contains the autogenerated documentation from the docstrings and the other place I adapted an example from pydy to show how to use the new class.

After working on SymbolicSystem I decided to try to finish off an old PR of mine regarding the init_printing code that Jason and I had discussed at Scipy. The idea was to build separate dictionaries to pass to the different printers in ipython based on the parameters that the specific printers take. The idea was to find this information using inspect.getargs(). The problem arose when trying to implement this solution because each separate printer has an expr argument and a **settings argument and the different possible paramters are processed internally by the printer. This means that there would not be an elegant way to build dictionaries for each printer.

The next thing I worked on this week was looking into Jain’s version of the order(N) method as suggested last week. When I started looking over his book, however, I found that uses a rather different set of notion than Featherstone and had some additional terms. I have decided to move forward with Featherstone’s method due to the summer coming to an end and I am already familiar with his version of the method. To that end I reread the first part of chapter 7 in Featherstone’s book where he discusses the articulated body method.

I reviewed two PR’s this week. This work was rather quick as they were simply documentation additions. I verified the method docstrings matched what the mehtod actually does and that the modual docstring included the different functions present in the file. Determining that they were correct I gave the +1 to merge and they have both since been merged.

Future Directions

The plan for next week is to focus entirely on the order(N) articulated body method of forming the equations of motion. I plan on writing the three passes for the method as if I have all of the information and methods I need in order to make it work. I expect this to be the best way to determine what additional code I will need in addition to finding my weak points in how well I understand the method. Once I have a skeleton of the of how the algorithm is supposed to work I will stop working directly on the algorithm itself and start working on the peripheral code such as the joints and body code or spatial vector processing methods.

PR’s and Issues

  • (Open) [WIP] Added to physics/mechanics PR #11431
  • (Merged) Added docstrings to delta and mid property methods PR #11432
  • (Merged) Added top-level docstring for PR #11440

July 28, 2016


Previous week I had implemented the Shoup’s Algorithm in this PR. During the review we came to realise that it is better to use unsigned int instead of integer_class because we didn’t need big numbers.

Working on the same PR, I found a bug in negate and similar function where we were doing:

for (auto &a : dict_) {
  a *= -1;
  a += modulo_;

Here: if the dict_ is [0, 0, 10], it will negate to [11, 11, 1] in GF(11). So, it was needed to add a check when the value is 0. So, the method was changed to:

for (auto &a : dict_) {
  a *= -1;
  if (a != 0_z)
    a += modulo_;

Along with it I was working on the gf_factor PR and it eventually got merged. It introduced Zassenhaus’s algorithm and gf_factor() function. In coming days, we will have to change gf_factor to switch between gf_zassenhaus and gf_shoup according to the degree of polynomial.

We made one more design change, we changed the factor container from std::pair<GaloisFieldDict, integer_class> to std::pair<GaloisFieldDict, unsigned> because we didn’t need large numbers as power.

Then I started working on change of base class of GaloisField class from UPolyBase to UIntPolyBase, this needed implementation of eval and multi_eval method, then I implemented the iterator for GaloisField class and the pow method. The PR is under review.

July 24, 2016

I couldn’t write a blog post last week so including progress of week 8 and 9 both here.

Week 8

I continued working on the PR #11360. We added functionality to store a different type of initial condition for regular singular points other than the usual [y(0), y'(0), ...]. The exact format is described here in master, though it is changed to a more elegant form in #11422. This type of initial condition provides more information at regular singular points and is helpful in converting to expressions. Examples on how to use it:

In [22]: expr_to_holonomic(sin(x)/x**2, singular_ics={-1: [1, 0, -1]}).to_expr()

I also added method to compute this type of initial condition for algebraic functions of the form P^r, for some Polynomial P and a Rational Number R.

In [25]: expr_to_holonomic(sqrt(x**2+x))
Out[25]: HolonomicFunction((-x - 1/2) + (x**2 + x)Dx, x), {1/2: [1]}

In [26]: _25.to_expr()
√x⋅╲╱ x + 1

After that I made some changes in `to_meijerg()` to return the polynomial itself if the `meijerg` function represents a polynomial instead of raising `NotImplementedError`.

In [40]: expr_to_holonomic(4*x**3 + 2*x**2, lenics=3).to_meijerg().expand()
   3      2
4⋅x  + 2⋅x

I also added code to return the general solution in `_frobenius()` if none of the roots of indicial equation differ by an integer.

Week 9

I wasn’t able to do much this week because my college started. I travelled back and had some college related stuff to do.

I opened #11422 and first added a basic method to determine the domain for polynomial coefficients in the differential equation.

In [77]: expr_to_holonomic(sqrt(y*x+z), x=x, lenics=2).to_expr()
╲╱ x⋅y + z

In [78]: expr_to_holonomic(1.1329138213*x)
Out[78]: HolonomicFunction((-1.1329138213) + (1.1329138213*x)Dx, x), f(0) = 0

Then I added support for the new type of initial condition on regular singular points in .integrate().

In [83]: expr_to_holonomic(sin(x)/x**3, singular_ics={-2: [1, 0, -1]}).integrate(x).to_expr()
 ⎛ 2                          ⎞
-⎝x ⋅Si(x) + x⋅cos(x) + sin(x)⎠

Also added support for the same in addition.

In [6]: expr_to_holonomic(sqrt(x)) + expr_to_holonomic(sqrt(2*x))
Out[6]: HolonomicFunction((-1/2) + (x)Dx, x), {1/2: [1 + sqrt(2)]}

In [7]: _6.to_expr()
Out[7]: √x⋅(1 + √2)

I plan to continue my work on this PR and add more support for this initial condition.

In the last blog post I reported that lambdify function was fully wrapped. Yes, that’s what I thought at the time! But it did indeed dragged on quite a bit, requiring many changes, which were very educative for me in terms of how Ruby looks at user experience. Several changes were done, including structural changes on calling lambdify, and for supporting older Ruby versions. The really interesting and long discussions on this can be viewed in the PR 61.

Apart from that, simultaneously I started reading and exchanging ideas on exception handling. It was agreed that in the C wrappers, an error code to be returned, which can be accessed from the Ruby wrapper, which in turn can raise a Ruby exception. The preliminary model can be seen in PR 1044 in SymEngine and PR 64 in SymEngine Ruby wrapper.

Right now any exception is caught and sent to the Ruby Wrapper with an error code of -1, which raises a generic Runtime Error in Ruby. Although not very informative, this is helpful in prevention of crashing the Ruby runtime.

To illustrate, when the following code (a division by zero) is run before and after is shown.


irb(main):001:0> require 'symengine'
=> true
irb(main):002:0> x = SymEngine(1)
=> #<SymEngine::Integer(1)>
irb(main):003:0> y = SymEngine(0)
=> #<SymEngine::Integer(0)>
irb(main):004:0> x/y
terminate called after throwing an instance of 'Teuchos::NullReferenceError'
  what():  /home/rajith/Development/symengine/symengine/utilities/teuchos/Teuchos_RCPNode.cpp:720:

Throw number = 1

Throw test that evaluated to true: true

Teuchos::RCP<SymEngine::Basic const> : You can not call operator->() or operator*() if getRawPtr()==0!

Abort caught. Printing stacktrace:

Traceback (most recent call last):

[2]    590 abort (core dumped)  irb


irb(main):001:0> require 'symengine'
=> true
irb(main):002:0> x = SymEngine(1)
=> #<SymEngine::Integer(1)>
irb(main):003:0> y = SymEngine(0)
=> #<SymEngine::Integer(0)>
irb(main):004:0> x/y
RuntimeError: Runtime Error
    from (irb):4:in `/'
    from (irb):4
    from /usr/bin/irb:11:in `<main>'

This is a good improvement overall, but as it’s nicer to have a more descriptive error shown to the user, that part will be the continuation of exception handling during the 10th week.

See you next week!

This week I worked on solving trigonometric inequalities.

Trigonometric inequalities

The primary univariate inequality solver - solve_univariate_inequality,
depends upon the results of solve in order to solve the given inequality. Taking a cue from PR#10022 on incorporating solveset for inequalities, I worked on developing an approach for replacing the use of solve with solveset in solving inequalities.


Convert Set-type output from solveset to list objects similar to that returned by solve.

The most striking difference between both the APIs is the uniform Set output returned by solveset. Hence, the prime concern while transitioning from solve to solveset should be handling the various type of solutions.

Here are a few implementation ideas on the same:

  • FiniteSet : finite number of solutions
    Using the list constructor on these type of objects works extremely well.

  • ImageSet : infinite number of solutions
    This is generally the case with trigonometric functions as most of them are periodic in nature. We need to limit the number of solutions to be finite.
    For this, I intend to use the a periodic interval: [0, period] as the basis for filtering the solution set. This returns a simplified FiniteSet of solutions which can be used to solve inequalities in a restricted interval. Following which we can generalise the output over the entire domain of the function.

    A major issue here is the representation of the final solution set.
    For example:

    In []: solveset(cos(x)<0, x, domain=S.Reals)
             π           3⋅π
    2*n*pi + , 2*n*pi + ───  | n  ℤ⎥
             2            2

    Currently, we do not have a Set object for representing this.
    For this, we need to implement an Indexed Union : Union(X(a) for a in I)

    We can symbolically represent the above solution as BigUnion(Interval(2*n*pi + pi/2, 2*n*pi + 3*pi/2), n, S.Intgers).

After thoughts

Also, this week my PR#11277 on periodicity got merged finally. I have updated the corresponding PR#11141 which has been stalled for some time now. Hopefully, it will get merged soon.

The next week I will devote my time to the implementation part of solving inequalities.

July 23, 2016


Sorry I haven’t been able to report my work for about two weeks now. Things have become slower mainly due to the fact that my university has resumed and along with it a heavily packed timetable and assignments in the first week don’t help. I also caught a bad fever the past week which really hindered my progress, but it’s dying down and I will resume my work with full vigor eventually.

The work I did do has been summarized below.

Bug Fixes

While writing the code for the rational polynomials, as mentioned in the last blogpost, I encountered various bugs. Some of them caused other bugs to be exposed, which took a lot of time for me to debug.

  • pow(Poly, uint) was throwing a segmentation fault. After digging in and wasting more than four hours on unrelated checks I figured out that the eq inside the polynomial class was incorrect. Without checking whether the other parameter was a Poly or not, I was static_casting it which posed a problem.

  • The happiness was shortlived, as the bug persisted. On further inspection I found that the polynomial was being treated as a number! This was because is_a_Number relied on typecodes, and the polynomial types were defined before the NUMBERWRAPPER class, which deemed them numbers. The fix for this was simple, just move the polynomial type code definitions after the numbers.

  • The pow tests pass, but what’s this? All the MSVC builds on appveyor fail. They all fail a coeff test. Wow, I had not changed any code related to coeff at all, how does it affect that specific test and only on the MSVC compiler? This kept me wondering and looking at the source for a day. Finally, I had to login to the VM of appveyor running the tests. I was not familiar with windows development environment at all, which was the reason I failed a couple of times before I gave up debugging. The next morning I woke up determined to fix this Windows bug, I set the break points in Visual Studio and started the code execution. I found it! It was a bug in the CoeffVisitor itself. The code for the coeff function was incomplete. Why wasn’t this bug being captured before? Probably because the previous change (in the typecodes) caused a reordering in a map, which no other compiler was doing. Do read up here for more details.

  • An appveyor build was failing for unknown reason, which had to be shifted to allowed failures

This was basically the components of #1033. Less quantity of changes, but really important none the less.

Rational Polynomials

The work with rational polynomials continues. I had underestimated the amount of work required, and I also feel that I should have broken down rational polynomials into three parts each, just like integer polynomials. Right now, the work continues in #1028, but it’s soon going to become huge with all varieties of changes.


I finally benchmarked cotire to see how much speedup it was providing to SymEngine builds. Here is the short summary of the speedups obtained, and the work to include it is in #1041.

Also a small bug was present in our flint and gmp rational number wrappers. We were not canonicalizing on construction from two integers. It was fixed in #1031.


July 22, 2016

Hello, guys. Welcome back. It’s been nine weeks into the coding period. I had a meeting with Jason on 17th  of this month. He was attending the code sprints at Scipy and I am very glad to meet other Sympy developers.

So Far

  • I have closed the PR 11266.
  • In PR 11374, I have removed the use of mechanics Point.
  • I have made boundary_conditions as property and the inputs are no longer as **kwargs. Each of the inputs namely moment, slope and deflection are initiated as an empty list. But I have some doubts regarding the behaviour of this method. I feel that this should be used only in the case when a full new set of boundary conditions are given as input. Since to input dynamically, there exists some methods already which would handle each of the cases explicitly. Those methods appends the new inputs whereas this method would delete the existing boundary conditions and apply the newer one. This way the property of being mutable would remain.
  • Replaced the solve function by linsolve. Since solve is going to be depreciated in the mear future.
  • I have added the docstrings for slope and deflection method as well as for the beam class.
  • In deflection method, I have added a new case where if there is no slope boundary condition but there is deflection boundary conditions, it would give operate.

Next Week

  • I will be working on adding a documentation file for this beam bending problem module exclusively.
  • Add some more test for checking the corner cases.

That’s all for this week. Cheers !!

Happy Coding.

Last week I did not end up writing a blog post and so I am combining that week’s post with this week. Last week I attended the SciPy 2016 conference and was able to meet my mentor, and many other contributers to SymPy, in person. I was also able to help out with the Pydy tutorial. During this time at the conference (and this current week) I was able to flesh out the remaining details on the different portions of the project. I have updated PR #353 to reflect the api decisions for SymbolicSystem (previously eombase.EOM).

In line with trying to put the finishing touches on implementation details before diving in to code, Jason and I met with someone who has actually implemented the algorithm in the past to help us with details surrounding Featherstone’s method. He also pointed me to a different description of the same algorithm that may be easier to implement.

This week I also worked on rewriting the docstrings in physics/mechanics/ because I found the docstrings currently there to be somewhat confusing. I also did a review on one of Jason’s PR’s where he reduces the amount of work that *method.rhs() has to do when inverting the mass matrix by pulling out the kinematical information before the inversion takes place.

Future Directions

With the work these past two weeks being focused on implementing the different parts of the projects, I will start implementing these various parts next week. I will first work on finishing off the SymbolicSystem object and then move towards implementing the OrderNMethod. This work should be very straight forward with all the work that has been put into planning the api’s.

PR’s and Issues

  • (Merged) Speeds up the linear system solve in KanesMethod.rhs() PR #10965
  • (Open) Docstring cleanup of physics/mechanics/ PR #11416
  • (Open) [WIP] Created a basis on which to discuss EOM class PR #353

Older blog entries

Planet SymPy is made from the blogs of SymPy's contributors. The opinions it contains are those of the contributor. This site is powered by Rawdog and Rawdog RSS. Feed readers can read Planet SymPy with RSS, FOAF or OPML.
